Custom PCB Design
for Peak Performance

A: ByteSnap offers custom PCB design services, including conception, development, prototyping, final product production, and long-term support for both low-volume electronic prototypes and high-volume complex products

Since 2008, ByteSnap has built a reputation for excellence in PCB design, backed by over 17 years of industry expertise. We specialize in high-layer-count PCB designs, precision 0201 components, and high-speed interfaces, including intricate 500+ ball BGAs. Our capabilities extend to flex-rigid configurations and designs operating at voltages up to mains levels, ensuring robust solutions for even the most demanding technical requirements.

Yes, alongside our electronics hardware team, ByteSnap has several software teams that work together seamlessly on embedded electronics projects, ensuring effective communication across all design aspects.

ByteSnap has experience working with companies from industrial, security,  medical, or connected devices through to consumer electronics. We work across most vertical market segments, tailoring designs to specific requirements and industry standards. It is very likely that we have dealt with another company in your industry.

ByteSnap has a multistage process for design of PCBs starting with development of a specification of the product if this hasn’t been provided. Once this is done, the schematic design is done and then checked internally by another engineer. This is then released to the customer for sign off. The PCB layout is then conducted providing 3D step files of the board to check against the mechanical design. This followed by internal and customer reviews and any resulting changes. At this point the initial prototypes are produced and testing begins.

The number of prototypes spins beyond a revision B is usually defined by the customer depending on if this is a high-volume part or a demonstrator for R&D purposes. A Production Pack is produced as the final output of the design work.

Yes, ByteSnap can add members to your team or deliver a package of work in its entirety, offering either end-to-end design assistance or support for in-house employees as needed.

A design is only as good as the manufacturer that makes the boards. ByteSnap can develop end of line testing equipment to ensure quality and help to achieve high levels of reliability. ByteSnap designs with best practises in mind and can provide assistance with CE marking or equivalent globally. Working with a partner, ByteSnap have designed and built products without a single failure in the field, despite thousands of devices being made.

Yes, ByteSnap has worked on projects where there will only ever be three units in the field, up to devices produced at three million units per year . We tailor designs to accommodate various production needs, including low batch volumes and complex manufacturing processes.

By choosing ByteSnap, you can expect an expert team with a great deal of experience We deliver: engineering excellence, custom solutions, high-precision PCBs, faster time-to-market, improved product performance, and reliable designs that safeguard your investments and reputation

You can contact ByteSnap HERE with your project requirements and we can setup a call to discuss the process of creating custom PCB designs tailored to your needs.
